![](https://www.hattersley.com/app/uploads/2023/09/Fig.28_GateValves_Hattersley-BF-1024x723.jpg)
Fig. 28
Gate Valves - Lever Operated - Bronze
1/2" to 3"
![BIM File Available](https://www.hattersley.com/app/themes/hattersley/assets/images/product-flags/bim.png)
![](https://www.hattersley.com/app/uploads/2023/09/Fig.30_30LS_GateValves_Hattersley-BF-1024x723.jpg)
![WRAS Approved Product](https://www.hattersley.com/app/themes/hattersley/assets/images/product-flags/wras-large.png)
Fig. 30 & 30LS
Gate Valve - DZR Brass
1/2" to 2"
- Taper threaded BS EN 10266 (ISO 7-1) formerly BS 21
- BSEN12288 PN20 Series B
9 bar at 180°C
20 bar from -10 to 100°C
WRAS Approved Product to 85°C
![BIM File Available](https://www.hattersley.com/app/themes/hattersley/assets/images/product-flags/bim.png)
![](https://www.hattersley.com/app/uploads/2023/09/Fig.30CLS_GateValves_Hattersley-BF-1024x723.jpg)
![WRAS Approved Product](https://www.hattersley.com/app/themes/hattersley/assets/images/product-flags/wras-large.png)
Fig. 30C & 30CLS
Gate Valves - Bronze
15mm to 54mm
- Compression ends to BS EN 1057:2006: Half hard R250.
![BIM File Available](https://www.hattersley.com/app/themes/hattersley/assets/images/product-flags/bim.png)
![](https://www.hattersley.com/app/uploads/2023/09/Fig.33_GateValves_Hattersley-BF-1024x723.jpg)
Fig. 33
Gate Valves - Bronze
1/4" to 2"
- Threaded to BS EN 10226-2.
![BIM File Available](https://www.hattersley.com/app/themes/hattersley/assets/images/product-flags/bim.png)
![](https://www.hattersley.com/app/uploads/2023/09/Fig.33X_33XLS_GateValves_Hattersley-BF-1024x723.jpg)
![WRAS Approved Product](https://www.hattersley.com/app/themes/hattersley/assets/images/product-flags/wras-large.png)
![BSI Kitemark](https://www.hattersley.com/app/themes/hattersley/assets/images/product-flags/bsikitemark.png)
Fig. 33X & 33XLS
Gate Valves - Bronze
1/4" to 4"
- Taper threaded BS EN 10226 formerly BS 21
![BIM File Available](https://www.hattersley.com/app/themes/hattersley/assets/images/product-flags/bim.png)
![](https://www.hattersley.com/app/uploads/2023/09/Fig.501_GateValve_Hattersley-BF-1024x723.jpg)
Fig. 501
Gate Valves - Cast Iron
2" to 12"
- Flanged to ANSI B16.1 Class 125 and BS 1560 3.2
![BIM File Available](https://www.hattersley.com/app/themes/hattersley/assets/images/product-flags/bim.png)
![](https://www.hattersley.com/app/uploads/2023/09/Fig.504_GateValves_Hattersley-BF-1024x723.jpg)
Fig. 504
Gate Valves - Cast Iron
50mm to 600mm
- Flanged to ANSI B16.1 Class 125
![BIM File Available](https://www.hattersley.com/app/themes/hattersley/assets/images/product-flags/bim.png)
![](https://www.hattersley.com/app/uploads/2023/09/Fig-589_SA_RSGV_-Hattersley-a-BF-1024x723.jpg)
![WRAS Approved Product](https://www.hattersley.com/app/themes/hattersley/assets/images/product-flags/wras-large.png)
Fig. 589 HW & Fig.589 SA
Resilient Seated Gate Valve (RSGV) - Ductile Iron
50mm – 300mm
- Flanged to BS EN 1092-2
![](https://www.hattersley.com/app/uploads/2023/09/Fig.609_GateValves_Hattersley-BF-1024x723.jpg)
Fig. 609
Gate Valves - Bronze
1/2" to 2"
- Taper threaded BS EN 10226 (ISO 7-1) formerly BS 21.
![BIM File Available](https://www.hattersley.com/app/themes/hattersley/assets/images/product-flags/bim.png)
![](https://www.hattersley.com/app/uploads/2023/09/Fig.669_GateValves_Hattersley-BF-1024x723.jpg)
Fig. 669
Gate Valves - Bronze
1/2" to 2"
- Taper threaded BS EN 10226 (ISO 7-1) formerly BS 21.
![BIM File Available](https://www.hattersley.com/app/themes/hattersley/assets/images/product-flags/bim.png)
![](https://www.hattersley.com/app/uploads/2024/01/Fig-C31_Gate-Valves_Hattersley-1024x722.jpg)
Fig. C31
Gate Valves - Bronze
1/2" to 2"
- Taper threaded BS EN 10226 (ISO 7-1) formerly BS 21.
![BIM File Available](https://www.hattersley.com/app/themes/hattersley/assets/images/product-flags/bim.png)
![](https://www.hattersley.com/app/uploads/2023/09/Fig.C618_GateValves_Hattersley-BF-1024x723.jpg)
Fig. C618
Export Gate Valve - Bronze
1/2" to 2"
- Taper threaded BS EN 10226 (ISO 7-1) formerly BS 21.
![BIM File Available](https://www.hattersley.com/app/themes/hattersley/assets/images/product-flags/bim.png)
![](https://www.hattersley.com/app/uploads/2023/09/Fig.511_GateValves_Hattersley-BF-1024x723.jpg)
Fig. M511
Gate Valves - Cast Iron - Available until stocks last
50mm to 150mm
- Flanged to BS EN 1092-2 PN10
![BIM File Available](https://www.hattersley.com/app/themes/hattersley/assets/images/product-flags/bim.png)
![](https://www.hattersley.com/app/uploads/2023/09/Fig.M540_GateValves_Hattersley-BF-1024x723.jpg)
Fig. M540
Gate Valves - Ductile Iron - Available until stocks last
50mm to 150mm
- Flanged to BS EN 1092-2 PN25
![BIM File Available](https://www.hattersley.com/app/themes/hattersley/assets/images/product-flags/bim.png)
![](https://www.hattersley.com/app/uploads/2023/09/Fig.M541_M541E_gatevalves_Hattersley-BF-1024x723.jpg)
Fig. M541
Gate Valves - Cast Iron
50mm to 300mm
- Flanged to BS EN 1092-2 PN16
![BIM File Available](https://www.hattersley.com/app/themes/hattersley/assets/images/product-flags/bim.png)
![](https://www.hattersley.com/app/uploads/2024/01/M544-Gate-Valve-Hattersley-1024x722.jpg)
Fig. M544
Gate Valves - Ductile Iron
65mm to 300mm
- Flanged to BS EN 1092-2 PN16
![BIM File Available](https://www.hattersley.com/app/themes/hattersley/assets/images/product-flags/bim.png)
![](https://www.hattersley.com/app/uploads/2023/09/Fig.M549_M549E_GateValves_Hattersley-BF-1024x723.jpg)
Fig. M549
Gate Valves - Cast Iron - Available until stocks last
50mm to 300mm
- Flanged to BS EN 1092-2 PN6
![BIM File Available](https://www.hattersley.com/app/themes/hattersley/assets/images/product-flags/bim.png)
